UES60LCP-200300SPC

The UES60LCP-200300SPC is a high-performance power supply charger designed for medical and communication applications. This UE Electronic portable device charger is a reliable and versatile solution for powering medical devices, electronic gadgets, and more.

  • Compliant with communications and medical safety certifications
  • 2 MOPP isolation protection
  • Leakage current ≤ 100
  • DOE efficiency level VI
  • Standby power consumption≤0.15W
  • Working altitude 5000 meters
  • 5V by 20V Output, up to 60W
  • Support USB PD3.0 fast charging protocol
PDF file download
Product Features
Input voltage90-264VACOperating temperature0 ~ 40 ℃
Input Current1.3AStorage temperature-40 ~ 80℃
Average efficiencyDOE VI & CoC V5 Tier2(2016)(I.e.Under non-concentrated conditions, humidity 10% ~ 90%
Standby power consumption0.15W MAXmean time between failuresAt an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight180gMechanical specifications97.0(L)  63.5(W)  33.5(H)mm
Application placesSuitable for charging medical equipment, mobile phones, PDAs and other portable devicesSafety standards

CE(EN62368-1)、NRTL(UL62368-1)、NOM(NOM-001-SCFI-2018)、CB(IEC60601-1/IEC62368-1)、CCC(GB4943.1)、FCC(PART 15)、BSMI(CNS14336-1)、 RCM(AS/NZS62368.1)、PSE(J62368-1)、TUV-GS(EN62368-1)、UL(ANSI/AAMI ES60601-1 CAN/CSA-C22.2NO.60601-1)、TUV-SUD/Mark(EN60601-1)

modelVoltage(V)Current(A)Ripple(mVpk-pk)
115 230		Average efficiency
（%）Min
UES60LCP-200300SPC5.00.01-3.00150Y Y81.39
9.00.01-3.00150Y Y86.62
12.00.01-3.00150Y Y87.40
15.00.01-3.00150Y Y87.73
20.00.01-3.00150Y Y89.00

The UES60LCP-200300SPC is a high-performance power supply charger ideal for medical and communication applications.

  • Medical Applications

As a medical charger, UES60LCP-200300SPC complies with strict safety certifications and features 2 MOPP isolation protection, ensuring reliable and safe operation for sensitive medical devices. With ultra-low leakage current (≤ 100 µA), UE Electronic power supply charger UES60LCP-200300SPC is ideally suited for powering critical equipment such as monitors, portable diagnostic tools, and other electronic devices in hospitals, clinics, or home environments.

  • Communication Applications

This UE Electronic USB charger power is designed to meet the demanding needs of communication devices, delivering 5V to 20V output and up to 60W power. Supporting the USB PD3.0 fast charging protocol, UES60LCP-200300SPC functions as a power fast charger for communication tools, ensuring quick and efficient operation. Our charger for electronic devices’s high-altitude capability (up to 5000 meters) makes it ideal for remote communication setups.

  • General Use

As a versatile portable device charger, the UES60LCP-200300SPC combines DOE Level VI energy efficiency with low standby power consumption (≤ 0.15W). UES60LCP-200300SPC can be used as a 12V charger power supply for various gadgets, the fastest USB phone charger, or a charger for electronic devices, making it an eco-friendly and reliable solution for both professional and everyday use.

1. What types of devices can the UES60LCP-200300SPC charge?

The UES60LCP-200300SPC is a versatile power supply charger suitable for medical equipment, mobile phones, PDAs, and other portable electronic devices. It functions as a reliable medical charger, a USB charger power supply, and a power fast charger for a variety of applications.

Yes, this power supply charger complies with medical safety certifications, including IEC60601-1 and UL60601-1. It features 2 MOPP isolation protection and leakage current ≤ 100 µA, making it a trusted medical charger for sensitive devices.

Absolutely! The UES60LCP-200300SPC supports the USB PD3.0 fast charging protocol, delivering up to 60W of power across a 5V to 20V output range. It is ideal for use as the fastest USB phone charger or a high-speed charger for electronic devices.

This USB charger power supply meets DOE Level VI and CoC V5 Tier 2 efficiency standards. It has a low standby power consumption of ≤ 0.15W, ensuring it is eco-friendly and energy-efficient.

Yes, the power supply charger is compact and lightweight, with dimensions of 97.0 × 63.5 × 33.5 mm and a weight of just 180g. Its portability makes it an excellent portable device charger for professionals and consumers on the go.

The UES60LCP-200300SPC is designed to operate reliably at altitudes up to 5000 meters, making it a suitable charger for electronic devices in high-altitude environments.

This power supply charger has a mean time between failures (MTBF) of 100,000 hours at an ambient temperature of 25°C. Its robust design ensures durability and reliability for extended use.

Yes, the power supply charger operates in temperatures ranging from 0°C to 40°C and can be stored in temperatures from -40°C to 80°C. It also handles humidity levels of 10% to 90% under non-condensing conditions.

Input voltage90-264VACOperating temperature0 ~ 40 ℃
Input Current1.3AStorage temperature-40 ~ 80℃
Average efficiencyDOE VI & CoC V5 Tier2(2016)(I.e.Under non-concentrated conditions, humidity 10% ~ 90%
Standby power consumption0.15W MAXmean time between failuresAt an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight180gMechanical specifications97.0(L)  63.5(W)  33.5(H)mm
Application placesSuitable for charging medical equipment, mobile phones, PDAs and other portable devicesSafety standards

CE(EN62368-1)、NRTL(UL62368-1)、NOM(NOM-001-SCFI-2018)、CB(IEC60601-1/IEC62368-1)、CCC(GB4943.1)、FCC(PART 15)、BSMI(CNS14336-1)、 RCM(AS/NZS62368.1)、PSE(J62368-1)、TUV-GS(EN62368-1)、UL(ANSI/AAMI ES60601-1 CAN/CSA-C22.2NO.60601-1)、TUV-SUD/Mark(EN60601-1)

modelVoltage(V)Current(A)Ripple(mVpk-pk)
115 230		Average efficiency
（%）Min
UES60LCP-200300SPC5.00.01-3.00150Y Y81.39
9.00.01-3.00150Y Y86.62
12.00.01-3.00150Y Y87.40
15.00.01-3.00150Y Y87.73
20.00.01-3.00150Y Y89.00

Product information

Application Field

Charger, medical related, communication related
