UES65-SPAZ
The UES65-SPAZ series is a compact and reliable solution within UE Electronic’s power portfolio, delivering stable performance across multiple power supply adapters categories. Designed for global certification needs, it supports power supply socket types and universal AC power adapter applications. As a trusted power adapter supplier with a complete EMC laboratory and full verification equipment, UE Electronic ensures precise and safe power supply AC adapter operation. The model also complies with medical requirements, making it a dependable medical switching power supply and medical power supply choice.
- Medical and ITE safety certification
- 2 MOPP isolation protection
- Leakage current ≤ 50μA
- DOE Level XNUMX Energy Efficiency
- CoC V5 Tier 2
- Standby power consumption≤0.15W
- 9V至24V,48V至54V输出, 最高65W
- Working altitude 5000 meters
- There are 4 AC socket types for input
- Covers short circuit protection, overvoltage protection, and overload protection;
Product Features
| Input voltage | 90-264VAC | Working temp. | 0 ~ 40 ℃ |
| Input Current | 2A | Storage temperature | -20 ~ 60℃ |
| Output voltage range | ± 5% | (I.e. | Under non-concentrated conditions, humidity 10%~90% |
| Standby power consumption | 0.15W MAX | mean time between failures | At an ambient temperature of 25°C, the mean time between failures at maximum load is 50,000 hours (according to MIL-HDBK-217 standard) |
| weight | 315g | Mechanical specifications | 125(L)×62(W)×34(H)mm |
| Application places | Suitable for medical and information equipment power adapters | Safety standards |
|
model | Voltage | Current | power | Ripple | Voltage tolerance | Linear and Negative Adjustment Rates | Average efficiency | Start delay time |
UES65-XXXYYYYSPAZ UES65-XXXYYYSPA1/ SPA2-OP
| 9.0-12.0 | 0.01-5.42 | 65.04 | 200 | ± 5% | Linear adjustment rate: ± 1%
Load: ±5 %
| 89.00% | ≤3s |
12.1-13.0 | 0.01-5.00 | 65.00 | 200 | ± 5% | 89.00% | ≤3s | ||
13.1-14.0 | 0.01-4.64 | 64.96 | 200 | ± 5% | 89.00% | ≤3s | ||
14.1-15.0 | 0.01-4.30 | 64.50 | 200 | ± 5% | 89.00% | ≤3s | ||
15.1-16.0 | 0.01-4.06 | 64.96 | 200 | ± 5% | 89.00% | ≤3s | ||
16.1-17.0 | 0.01-3.82 | 64.94 | 200 | ± 5% | 89.00% | ≤3s | ||
17.1-18.0 | 0.01-3.60 | 64.80 | 200 | ± 5% | 89.00% | ≤3s | ||
18.1-19.0 | 0.01-3.40 | 64.60 | 200 | ± 5% | 89.00% | ≤3s | ||
19.1-20.0 | 0.01-3.24 | 64.80 | 200 | ± 5% | 89.00% | ≤3s | ||
20.1-21.0 | 0.01-3.09 | 64.89 | 200 | ± 5% | 89.00% | ≤3s | ||
21.1-22.0 | 0.01-2.95 | 64.90 | 200 | ± 5% | 89.00% | ≤3s | ||
22.1-23.0 | 0.01-2.82 | 64.86 | 200 | ± 5% | 89.00% | ≤3s | ||
23.1-24.0 | 0.01-2.70 | 64.80 | 200 | ± 5% | 89.00% | ≤3s | ||
48.0 | 0.01-1.35 | 64.80 | 300 | ± 5% | 89.00% | ≤3s | ||
48.1-54.0 | 0.01-1.20 | 64.80 | 300 | ± 5% | 89.00% | ≤3s |
Overview
The UES65-SPAZ series is built for stable performance in both ITE and medical categories, providing flexible power supply adapters functions and dependable output control.
Medical Applications
As a qualified medical switching power supply, the UES65-SPAZ is designed to meet the stringent safety and reliability standards required in healthcare environments. It is ideally suited for powering a range of sensitive medical power supply applications, including portable diagnostic devices such as handheld ultrasound scanners, patient monitoring equipment, and mobile treatment systems. In low-power power supply medical scenarios, this model provides compliant and stable performance, with key electrical parameters including a low leakage current below 50 µA, high isolation rating of 90-264 VAC, and compliance with IEC 60601-1 standards. As a trusted power adapter supplier for the medical industry, we ensure that each unit delivers the precision and safety necessary for critical care and diagnostic environments.
Communication Applications
For ITE (Information Technology Equipment) and networking applications, this model excels as a reliable power supply AC adapter. It supports a wide range of global power supply socket types, ensuring compatibility across different regional standards. It is particularly effective in scenarios requiring stable ITE power supply 9v or power supply adapter 12v output for devices such as network switches, modems, VoIP equipment, and various data transmission modules. Designed with robust EMI filtering and surge protection, it maintains stable operation with input voltage ranges from 90 to 264 VAC and typical efficiency above 89%, making it a dependable switching power supply supplier solution for continuous communication infrastructure.
General Use
In broader commercial and consumer applications, the UES65-SPAZ serves as a versatile universal AC power adapter. Its compact form factor and adaptable design make it suitable for a variety of uses, including household electronics like Wi-Fi routers and security cameras, portable instruments such as digital multimeters and light boxes, as well as commercial equipment like point-of-sale systems and LED displays. As part of our range of flexible power supply adapters, it offers multiple DC output options, overload protection, and a wide operating temperature range of 0°C to 40°C (Storage temperature: -20 ~ 60℃), providing reliable performance across diverse environments and applications.
Q1: What is the UES65-SPAZ, and what industries is it designed for?
A: The UES65-SPAZ is a 65W desktop universal AC power adapter. It is a certified medical switching power supply and also serves as a compliant ITE power supply, making it ideal for powering both sensitive medical devices and information technology equipment.
Q2: What safety certifications does this medical power supply hold?
A: It is a fully certified medical device power supply that complies with key global standards, including IEC 60601-1, ANSI/AAMI ES60601-1 (UL), EN 60601-1 (TUV), and CAN/CSA C22.2 NO. 60601-1. It also holds an IEC 62368-1 GS-Mark for ITE use and multiple regional certifications for global markets.
Q3: What are the critical safety features for medical applications?
A: As a reliable medical power supplier, it incorporates 2 MOPP isolation, achieves a BF-type degree of protection, and maintains an extremely leakage current of ≤50µA, which is vital for patient safety.
Q4: What voltage outputs does it provide? Can it output 9V?
A: Yes, its DC output is adjustable across two ranges. In the lower range, it provides voltages from 9V up to 24V, making it suitable as an ITE power supply 9v. The higher range provides 48V to 54V output.
Q5: Why is it called a universal AC power adapter?
A: Its “universal” designation comes from two key features. First, it accepts a wide AC input voltage range of 90-264VAC. Second, it is offered with four different power supply AC inlet (e.g., C6, C8, C14, C18), allowing it to be used worldwide.
Q6: What are its key electrical performance specifications?
A: With a rated power of 65W, it offers high energy efficiency (DoE Level VI) and very low standby power consumption (≤0.15W). The average efficiency under typical load conditions is 89%.
Q7: What protections are built into this power supply ac adapter?
A: To ensure reliability, it includes comprehensive protection against output short circuits, overloads, and over-voltage conditions.
Q8: How reliable is it for continuous operation?
A: It is designed for robust performance with an operating altitude of up to 5,000 meters and a wide operating temperature range of 0°C ~ 40°C.
Q9: Can it function as a stable power supply adapter 12v?
A: Absolutely. Within its adjustable output range, the UES65-SPAZ can be set to provide a stable 12V output, serving as a precise power supply adapter 12v for various devices.
Q10: Who manufactures this product, and are they a reputable switching power supply supplier?
A: The UES65-SPAZ is manufactured by UE Electronic, an experienced power adapter supplier and switching power supply supplier with over 30 years of expertise. The company holds multiple quality management system certifications, ensuring high standards of quality and reliability.
