PoE Power Adapter - UE Electronic

PoE35-560062

POE35-560062 is a compact and stable PoE adapter designed for efficient power and data delivery. With UE Electronic’s over 30 years manufacturing experience, full EMC laboratory capability, and comprehensive testing systems, the product ensures consistent performance across various network environments. It supports functions of the PoE power adapter, delivering reliable PoE adapter power for IP cameras, terminals, and IoT devices. Compatible with multiple PoE adapters and PoE AC adapter scenarios, it integrates smoothly with communication systems requiring stable network adapter and PoE switch power supply interfaces.

  • AC input voltage 90-290VAC
  • Short Circuit, over current, over voltage protection
  • Comply with IEEE802.3af/at protocol
  • Average energy efficiency ≥85%
  • 支持10Mbps/100Mbps/1G/2.5G/5G/10G/以太网传输
  • Meets 6KV surge immunity level
PDF file downloadGet a quote
Product Features
Input voltage90-290VACWorking temp.-25 ~ 50℃
Input Current1.0AStorage temperature-40 ~ 85℃
Output voltage range± 5%Working humidityUnder non-concentrated conditions, humidity 5%-95%
weight205gmean time between failuresAt an ambient temperature of 25°C, the average time between failures at maximum load is 500,000 hours (According to Telcordia SR332standard)
Application placesSuitable for power supply of IP phones, wireless AP, POS equipment, programmable cameras and other network equipmentMechanical specifications171.0 (L)   62.0(W)  31.0(H)mm
  Safety standards

CE(EN62368-1)、cULus(UL62368-1)、CB/EAC/PSB(IEC62368-1)、CCC(GB4943.1)、KC(K62368-1)、RCM(AS/NZS62368.1)、BSMI(CNS14336-1)、PSE(J62368-1)、BIS(IEC60950-1)、NOM(NOM-001-SCFI-2018)

modelVoltage(V)Current(A)Ripple (mV)
115 230		Average efficiency
（%）Min
PoE35-56006256.00.01-0.62200Y Y85.00

General Overview

The PoE35-560062 is a versatile and robust PoE power adapter designed to provide stable Power over Ethernet (PoE) delivery for network devices requiring simultaneous data transmission and power. Designed with a wide AC input range of 90-290VAC for global compatibility and backed by rigorous quality control and comprehensive EMC testing, this unit is built for reliability in diverse PoE network environments. Its compact design (171.0×62.0×31.0mm) and light weight (205g) allow for easy integration or placement, making it an ideal external PoE switch power supply solution.

Communication Applications

This ethernet PoE adapter is ideal for a wide range of communication equipment, including IP phones, wireless access points (APs), POS systems, and programmable IP cameras. Compliant with the IEEE 802.3af/at PoE standard, it ensures protocol-level compatibility and consistent output when paired with other PoE infrastructure. Its capability to support network speeds from 10Mbps up to 5Gbps makes it future-proof for high-bandwidth applications, providing a reliable poe adapter power source for critical network nodes and IoT deployments.

Performance and Reliability

As a high-performance PoE AC adapter, it offers an average energy efficiency of ≥85% and delivers a stable 56V output. To ensure maximum uptime and protect connected equipment, it incorporates multiple safeguards, including short circuit, over current and over voltage protection, and boasts a high 6KV surge immunity rating. The product’s exceptional reliability is quantified by a Mean Time Between Failures (MTBF) of 500,000 hours at full load (25°C ambient), as per the Telcordia SR-332 standard. It operates reliably within a broad temperature range of -25°C to 50°C, suitable for various installation environments.

General Use & Compliance

Applicable in security systems, industrial automation, smart buildings and commercial electronics, this adapter PoE simplifies network adapter integration and PoE adapters deployment. It holds a comprehensive set of international safety certifications, including CE, cULus, CB, CCC, and KC, ensuring compliance and safety for global market deployment. This makes it a trustworthy and compliant choice for professional and commercial installations requiring dependable PoE power.

Q1. What is the PoE35-560062 and what are its main applications?

A: The PoE35-560062 is a PoE (Power over Ethernet) adapter, specifically a PoE power over ethernet adapter and PoE AC adapter. It is designed to supply power and data over a single Ethernet cable to network equipment such as IP phones, wireless access points (AP), POS terminals, and programmable cameras.

A: It complies with the IEEE 802.3af/at protocol, ensuring compatibility with a wide range of standard PoE-powered devices (PDs). This makes it a reliable and interoperable PoE adapter.

A: It features a wide AC input range of 90-290VAC. Its output is 56V DC with a current range of 0.01-0.62A, delivering a total power of 35W. Its average energy efficiency is ≥85%.

A: This adapter PoE supports a wide range of Ethernet transmission speeds, including 10Mbps, 100Mbps, 1Gbps, 2.5Gbps, and 5Gbps, ensuring compatibility with both current and future high-speed networks.

A: It includes short circuit, over current, and over voltage protection. It has a high immunity level of 6KV surge protection. Its reliability is rated with a mean time between failures (MTBF) of 500,000 hours at 25°C under maximum load.

A: This PoE power supply unit is designed to operate within a temperature range of -25°C to 50°C and can function in non-condensing humidity levels from 5% to 95%.

A: Yes, it holds a comprehensive set of global safety certifications, making it suitable for worldwide markets. These include CE, cULus, CB, CCC, KC, RCM, BSMI, PSE, BIS, and NOM, primarily meeting the IEC/EN/UL 62368-1 standard for IT and audio/video equipment.

A: It is a compact and lightweight PoE adapters unit. Its mechanical dimensions are 171.0mm (L) x 62.0mm (W) x 31.0mm (H), and it weighs approximately 205g.

A: While it provides similar power conversion functionality, the PoE35-560062 is an external PoE adapter power unit. It is typically used as a mid-span device to add PoE capability to a network that lacks a PoE-enabled switch, rather than as an internal network adapter or component.

A: Its listed safety certifications (IEC 62368-1) are for Information Technology Equipment (ITE) and Audio/Video equipment. Therefore, it is ideal for standard ITE and network devices but not be certified for direct use in medical-grade applications unless specified otherwise in additional documentation.

Input voltage90-290VACWorking temp.-25 ~ 50℃
Input Current1.0AStorage temperature-40 ~ 85℃
Output voltage range± 5%Working humidityUnder non-concentrated conditions, humidity 5%-95%
weight205gmean time between failuresAt an ambient temperature of 25°C, the average time between failures at maximum load is 500,000 hours (According to Telcordia SR332standard)
Application placesSuitable for power supply of IP phones, wireless AP, POS equipment, programmable cameras and other network equipmentMechanical specifications171.0 (L)   62.0(W)  31.0(H)mm
  Safety standards

CE(EN62368-1)、cULus(UL62368-1)、CB/EAC/PSB(IEC62368-1)、CCC(GB4943.1)、KC(K62368-1)、RCM(AS/NZS62368.1)、BSMI(CNS14336-1)、PSE(J62368-1)、BIS(IEC60950-1)、NOM(NOM-001-SCFI-2018)

modelVoltage(V)Current(A)Ripple (mV)
115 230		Average efficiency
（%）Min
PoE35-56006256.00.01-0.62200Y Y85.00
