UES65-SPAZ
The UES65-SPAZ series is a compact and reliable solution within UE Electronic’s power portfolio, delivering stable performance across multiple power supply adapters categories. Designed for global certification needs, it supports power supply socket types and universal AC power adapter applications. As a trusted power adapter supplier with a complete EMC laboratory and full verification equipment, UE Electronic ensures precise and safe power supply AC adapter operation. The model also complies with medical requirements, making it a dependable medical switching power supply and medical power supply choice.
- 医疗和ITE安全认证
- 2 MOPP 隔离保护
- 漏电流 ≤ 50μA
- DOE 六级能效
- CoC V5 Tier 2
- 待机功耗≤0.15W
- 9V至24V,48V至54V输出, 最高65W
- 工作海拨高度5000米
- 输入有4种AC插座形式
- 涵盖短路保护、过压保护、过载保护;
产品特性
| 输入电压 | 90-264VAC | 工作温度 | 0~40℃ |
| 输入电流 | 2A | 储存温度 | -20~60℃ |
| 输出电压范围 | ±5% | 湿度 | 非浓缩条件下，湿度10%~90% |
| 待机功耗 | 0.15W MAX | 平均故障间隔时间 | 在25℃环境温度下，最大负载工作平均无故障时间50,000小时(根据MIL-HDBK-217标准) |
| 重量 | 315g | 机械规格 | 125(L)×62(W)×34(H)mm |
| 应用场所 | 适用于医疗、信息设备类电源适配器 | 安规标准 |
|
型号 | 电压 | 电流 | 功率 | 纹波 | 电压公差 | 线性与负数调整率 | 平均效率 | 启动延迟时间 |
UES65-XXXYYYSPAZ UES65-XXXYYYSPA1/ SPA2-OP
| 9.0-12.0 | 0.01-5.42 | 65.04 | 200 | ±5% | 线性调整率: ±1%
负载调整率: ±5 %
| 89.00% | ≤3s |
12.1-13.0 | 0.01-5.00 | 65.00 | 200 | ±5% | 89.00% | ≤3s | ||
13.1-14.0 | 0.01-4.64 | 64.96 | 200 | ±5% | 89.00% | ≤3s | ||
14.1-15.0 | 0.01-4.30 | 64.50 | 200 | ±5% | 89.00% | ≤3s | ||
15.1-16.0 | 0.01-4.06 | 64.96 | 200 | ±5% | 89.00% | ≤3s | ||
16.1-17.0 | 0.01-3.82 | 64.94 | 200 | ±5% | 89.00% | ≤3s | ||
17.1-18.0 | 0.01-3.60 | 64.80 | 200 | ±5% | 89.00% | ≤3s | ||
18.1-19.0 | 0.01-3.40 | 64.60 | 200 | ±5% | 89.00% | ≤3s | ||
19.1-20.0 | 0.01-3.24 | 64.80 | 200 | ±5% | 89.00% | ≤3s | ||
20.1-21.0 | 0.01-3.09 | 64.89 | 200 | ±5% | 89.00% | ≤3s | ||
21.1-22.0 | 0.01-2.95 | 64.90 | 200 | ±5% | 89.00% | ≤3s | ||
22.1-23.0 | 0.01-2.82 | 64.86 | 200 | ±5% | 89.00% | ≤3s | ||
23.1-24.0 | 0.01-2.70 | 64.80 | 200 | ±5% | 89.00% | ≤3s | ||
48.0 | 0.01-1.35 | 64.80 | 300 | ±5% | 89.00% | ≤3s | ||
48.1-54.0 | 0.01-1.20 | 64.80 | 300 | ±5% | 89.00% | ≤3s |
Overview
The UES65-SPAZ series is built for stable performance in both ITE and medical categories, providing flexible power supply adapters functions and dependable output control.
Medical Applications
As a qualified medical switching power supply, the UES65-SPAZ is designed to meet the stringent safety and reliability standards required in healthcare environments. It is ideally suited for powering a range of sensitive medical power supply applications, including portable diagnostic devices such as handheld ultrasound scanners, patient monitoring equipment, and mobile treatment systems. In low-power power supply medical scenarios, this model provides compliant and stable performance, with key electrical parameters including a low leakage current below 50 µA, high isolation rating of 90-264 VAC, and compliance with IEC 60601-1 standards. As a trusted power adapter supplier for the medical industry, we ensure that each unit delivers the precision and safety necessary for critical care and diagnostic environments.
Communication Applications
For ITE (Information Technology Equipment) and networking applications, this model excels as a reliable power supply AC adapter. It supports a wide range of global power supply socket types, ensuring compatibility across different regional standards. It is particularly effective in scenarios requiring stable ITE power supply 9v or power supply adapter 12v output for devices such as network switches, modems, VoIP equipment, and various data transmission modules. Designed with robust EMI filtering and surge protection, it maintains stable operation with input voltage ranges from 90 to 264 VAC and typical efficiency above 89%, making it a dependable switching power supply supplier solution for continuous communication infrastructure.
General Use
In broader commercial and consumer applications, the UES65-SPAZ serves as a versatile universal AC power adapter. Its compact form factor and adaptable design make it suitable for a variety of uses, including household electronics like Wi-Fi routers and security cameras, portable instruments such as digital multimeters and light boxes, as well as commercial equipment like point-of-sale systems and LED displays. As part of our range of flexible power supply adapters, it offers multiple DC output options, overload protection, and a wide operating temperature range of 0°C to 40°C (Storage temperature: -20 ~ 60℃), providing reliable performance across diverse environments and applications.
Q1: What is the UES65-SPAZ, and what industries is it designed for?
A: The UES65-SPAZ is a 65W desktop universal AC power adapter. It is a certified medical switching power supply and also serves as a compliant ITE power supply, making it ideal for powering both sensitive medical devices and information technology equipment.
Q2: What safety certifications does this medical power supply hold?
A: It is a fully certified medical device power supply that complies with key global standards, including IEC 60601-1, ANSI/AAMI ES60601-1 (UL), EN 60601-1 (TUV), and CAN/CSA C22.2 NO. 60601-1. It also holds an IEC 62368-1 GS-Mark for ITE use and multiple regional certifications for global markets.
Q3: What are the critical safety features for medical applications?
A: As a reliable medical power supplier, it incorporates 2 MOPP isolation, achieves a BF-type degree of protection, and maintains an extremely leakage current of ≤50µA, which is vital for patient safety.
Q4: What voltage outputs does it provide? Can it output 9V?
A: Yes, its DC output is adjustable across two ranges. In the lower range, it provides voltages from 9V up to 24V, making it suitable as an ITE power supply 9v. The higher range provides 48V to 54V output.
Q5: Why is it called a universal AC power adapter?
A: Its “universal” designation comes from two key features. First, it accepts a wide AC input voltage range of 90-264VAC. Second, it is offered with four different power supply AC inlet (e.g., C6, C8, C14, C18), allowing it to be used worldwide.
Q6: What are its key electrical performance specifications?
A: With a rated power of 65W, it offers high energy efficiency (DoE Level VI) and very low standby power consumption (≤0.15W). The average efficiency under typical load conditions is 89%.
Q7: What protections are built into this power supply ac adapter?
A: To ensure reliability, it includes comprehensive protection against output short circuits, overloads, and over-voltage conditions.
Q8: How reliable is it for continuous operation?
A: It is designed for robust performance with an operating altitude of up to 5,000 meters and a wide operating temperature range of 0°C ~ 40°C.
Q9: Can it function as a stable power supply adapter 12v?
A: Absolutely. Within its adjustable output range, the UES65-SPAZ can be set to provide a stable 12V output, serving as a precise power supply adapter 12v for various devices.
Q10: Who manufactures this product, and are they a reputable switching power supply supplier?
A: The UES65-SPAZ is manufactured by UE Electronic, an experienced power adapter supplier and switching power supply supplier with over 30 years of expertise. The company holds multiple quality management system certifications, ensuring high standards of quality and reliability.
