产品特性
| 输入电压 | 90-264VAC | 工作温度 | -10~50℃ | ||||||||
| 输入电流 | 1.5A,在90VAC 输入条件下 | 储存温度 | -20~70℃ | ||||||||
| 输出电压范围 | ±5% | 工作湿度 | 10~90% | ||||||||
| 待机功耗 | 0.15W | 平均故障间隔时间 | >100,000hrs MIL-HDBK-217,在25℃环境温度下。 | ||||||||
| 重量 | 110g | 机械规格 | 76.2(L) 50.8(W) 27.5(H)mm | ||||||||
| 应用场所 | 适用于医疗、I.T.E.设备类电源适配器 | 安规标准 | CB( IEC60601-1/IEC62368)，NRTL(ANSI/AAMI ES60601-1，CAN/CSA-C22.2NO.60601-1)，TUV- Mark(EN60601-1)，UL(ANSI/AAMI ES60601-1) | ||||||||
| 型号 | 电压（V） | 电流（A） | 功率(W) | 纹波 (最大) mVpk-pk | 电压公差 | 线性与负数调整率 | 平均效率 | 启动延迟时间 |
UES65-XXXYYYSPA5 -OP
| 5.0 | 0.01-10.00 | 50W | 120 | ±5% |
线性调整率: ±1% 负载调整率: ±5%
| 89.0% | ≤3s |
5.1-6.0 | 0.01-8.50 | 51W | 120 | ±5% | 89.0% | ≤3s | ||
6.1-7.5 | 0.01-8.00 | 60W | 120 | ±5% | 89.0% | ≤3s | ||
7.6-8.0 | 0.01-7.50 | 60W | 120 | ±5% | 89.0% | ≤3s | ||
8.1-9.0 | 0.01-6.66 | 60W | 120 | ±5% | 89.0% | ≤3s | ||
9.1-10.0 | 0.01-6.00 | 60W | 120 | ±5% | 89.0% | ≤3s | ||
10.1-11.0 | 0.01-5.50 | 60W | 120 | ±5% | 89.0% | ≤3s | ||
11.1-12.0 | 0.01-5.42 | 65W | 120 | ±5% | 89.0% | ≤3s | ||
12.1-13.0 | 0.01-5.00 | 65W | 120 | ±5% | 89.0% | ≤3s | ||
13.1-14.0 | 0.01-4.64 | 65W | 120 | ±5% | 89.0% | ≤3s | ||
14.1-15.0 | 0.01-4.33 | 65W | 120 | ±5% | 89.0% | ≤3s | ||
15.1-16.0 | 0.01-4.06 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
16.1-17.0 | 0.01-3.82 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
17.1-18.0 | 0.01-3.61 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
18.1-19.0 | 0.01-3.42 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 19.1-20.0 | 0.01-3.25 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 20.1-21.0 | 0.01-3.09 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 21.0-22.0 | 0.01-2.95 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 22.1-23.0 | 0.01-2.82 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 23.1-24.0 | 0.01-2.70 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 24.1-27.0 | 0.01-2.40 | 65W | 200 | ±5% | 89.0% | ≤3s | ||
| 27.1-30.0 | 0.01-2.16 | 65W | 300 | ±5% | 89.0% | ≤3s | ||
| 30.1-33.0 | 0.01-1.96 | 65W | 300 | ±5% | 89.0% | ≤3s | ||
| 33.1-36.0 | 0.01-1.80 | 65W | 300 | ±5% | 89.0% | ≤3s | ||
| 36.1-39.0 | 0.01-1.66 | 65W | 300 | ±5% | 89.0% | ≤3s | ||
| 39.1-42.0 | 0.01-1.54 | 65W | 300 | ±5% | 89.0% | ≤3s | ||
| 42.1-45.0 | 0.01-1.44 | 65W | 300 | ±5% | 89.0% | ≤3s | ||
| 45.1-48.0 | 0.01-1.35 | 65W | 300 | ±5% | 89.0% | ≤3s |
