产品特性
输入电压 | 90-264VAC | 工作温度 | 0~50℃ (自然风冷) ; 0~60℃(带风扇) |
输入电流 | 1.5A Max | 储存温度 | -40~70℃ |
输出电压范围 | ±5% | 湿度 | 非浓缩条件下,湿度5%~90% |
待机功耗 | 0.3W Max | 平均故障间隔时间 | 在25℃环境温度下,最大负载工作平均无故障时间200,000小时(根据 MIL-HDBK-217标准) |
重量 | 250g | 机械规格 | 100.0 (L) 78.0 (W) 32.0(H)mm |
应用场所 | 适用于资讯、信息设备类 | 安规标准 | 符合CE(IEC62368-1)、cULus(UL62368-1)、CE(EN62368-1) |
型号 | 电压(V) | 电流(A) | 纹波(mV) | 115 230 | 平均效率 (%)Min |
---|---|---|---|---|---|
UES100-SPA-OP-M2 | 54.0 | 0.01-1.5 | 500 | Y Y | 88 |
12.0 | 0.01-1.5 | 120 |
