PoE90-560161
UE Electronic PoE90-560161 is a robust PoE power injector that provides efficient power and data transmission for network devices. This PoE switch adapter is perfect for powering a range of network devices such as cameras, IP phones, and other network equipment.
- 交流输入电压90-290VAC;
- 涵盖短路保护、过流保护、过压保护
- 功率因数≥0.9
- 符合 IEEE 802.3af/PoE++协议
- 支持10Mbps/100Mbps/1G/2.5G/5G/10G以太网传输
产品特性
| 输入电压 | 90-290VAC | 工作温度 | -40~65℃ | |||||||||
| 输入电流 | 1.8A | 储存温度 | -40~70℃ | |||||||||
| 输出电压范围 | ±3% | 工作湿度 | 非浓缩条件下，湿度5%~95% | |||||||||
| 重量 | 570g | 平均故障间隔时间 | 在25℃环境温度下，最大负载工作平均无故障时间100,000小时 (根据 MIL-HDBK-217F标准) | |||||||||
| 应用场所 | 适用于IP电话、无线AP、POS设备、可编程摄像头等等网络设备供电 | 机械规格 | 191.5 (本体长) /222.0 (含挂耳长) 80.0(宽) 40(高)mm | |||||||||
| 安规标准 |
| |||||||||||
| 型号 | 电压(V) | 电流(A) | 纹波(mV) | 平均效率 （%）Min |
|---|---|---|---|---|
| POE90-560161 | 56.0 | 0.09-1.61 | 200 | 85.0 |
The PoE90-560161 is a versatile PoE power adaptor designed for reliable power and data transmission across various network devices. With its wide AC input voltage range of 90-290VAC and robust protections, including short circuits, over-current, and over-voltage, the UE Electronic PoE switch adapter delivers safe and consistent performance. Supporting 10Mbps to 10G Ethernet transmission and compliant with IEEE 802.3af/PoE++ protocol, our PoE power adaptor is an ideal solution for powering modern devices.
IP Phones
The PoE switch adapter is ideal for powering IP phones in offices, call centers and remote work environments. By combining power and data transmission over a single Ethernet cable, this PoE power adaptor eliminates the need for additional power outlets and messy cabling. This makes deployment simpler, reduces installation costs, and ensures reliable voice communication with an uninterrupted power supply.
Wireless Access Points (APs)
For businesses, campuses, and large public spaces, the PoE switch adapter serves as a reliable power source for wireless APs. Its ability to support high-speed Ethernet transmission up to 10G ensures strong and consistent network coverage for multiple users. By reducing the need for separate power connections, the UE Electronic PoE network adapter streamlines the installation process for wireless infrastructure while ensuring steady, high-bandwidth connectivity.
POS Equipment
The PoE power injector is well-suited for powering POS (Point of Sale) systems in retail stores, restaurants, and other service environments. By providing a stable and consistent network power supply, our PoE power adaptor ensures smooth transaction processing and eliminates downtime. The compact design and robust power delivery of the PoE injector power simplify the setup of modern POS devices, making it an essential solution for cash registers, card readers, and other payment equipment.
Programmable Cameras
The PoE power adapter for cameras is perfect for programmable surveillance and IP cameras used in security systems, industrial monitoring, and innovative city projects. This camera power adapter combines a power supply and high-speed Ethernet transmission over a single cable, ensuring seamless video streaming with zero interruptions. The wide AC input range and advanced protection features allow the cameras to function reliably even in challenging environments. At the same time, the 10G network support enables real-time, high-resolution video transmission.
The PoE90-560161 is a robust PoE network adapter that combines power and data delivery into one streamlined solution. UE Electronic PoE switch adapter is ideal for applications requiring efficiency, high-speed connectivity, and reliable network power supply.
1. What is the input voltage range for the PoE90-560161 PoE switch adapter?
The PoE90-560161 PoE power injector supports an AC input voltage range of 90-290VAC, which allows it to function reliably across different regions and power grids. This broad input range ensures stable performance even in areas with fluctuating power supply, making this PoE switch adapter suitable for global applications.
2. What network speeds does the PoE90-560161 support?
The PoE90-560161 PoE network adapter is compatible with multiple Ethernet transmission speeds, including 10Mbps, 100Mbps, 1G, 2.5G, 5G, and 10G. This wide range ensures the PoE switch adapter can meet the requirements of modern high-speed networks, delivering both power and reliable data transmission for devices like IP cameras, access points, and network switches.
3. What safety and protection features does the PoE90-560161 PoE power adaptor include?
The PoE90-560161 PoE switch adapter comes with robust safety features, including short circuit protection, overcurrent protection, and overvoltage protection. These features help protect the PoE switch adapter and connected devices from unexpected power surges, electrical faults, or excessive current, ensuring stable and reliable operation over time.
4. Is the PoE90-560161 compliant with PoE standards?
Yes, the PoE90-560161 PoE network adapter adheres to the IEEE 802.3af/PoE++ protocols, which ensures compatibility with a wide range of PoE-enabled devices. This compliance allows this PoE switch adapter to safely and efficiently deliver power and data to network equipment like IP cameras, access points, and IP telephones.
5. What types of devices can the PoE90-560161 power?
The PoE90-560161 PoE network adapter is designed to power various PoE-enabled network devices, such as IP phones, wireless access points (APs), POS systems, and programmable IP cameras. UE Electronic PoE switch adapter’s ability to supply both power and data over a single Ethernet cable makes it ideal for communication systems, surveillance solutions, and retail environments.
6. What is the power factor of the PoE90-560161, and why is it important?
The PoE90-560161 PoE power injector has a high power factor of ≥0.9, which indicates efficient energy usage. A high power factor minimizes energy loss, reduces operating costs, and ensures the PoE switch adapter delivers consistent power to connected devices. This makes it an energy-efficient choice for commercial and industrial applications.
7. What applications is the PoE90-560161 best suited for?
The PoE90-560161 PoE power adaptor is highly versatile and ideal for powering network equipment such as IP phones, wireless access points, POS machines, and surveillance cameras. Our PoE switch adapter is commonly used in commercial buildings, offices, retail stores, industrial setups, and security systems where reliable power and data transmission are required.
8. What makes the PoE90-560161 PoE switch adapter suitable for high-performance networks?
The PoE90-560161 PoE network adapter supports Ethernet speeds up to 10Gbps while maintaining a stable network power supply, ensuring smooth and uninterrupted data transmission. This feature is crucial for high-performance networks, especially in environments that require fast and reliable connections, such as data centers, surveillance networks, and enterprise communication systems.
