UES36WZ-SPA - UE Electronic

UES36WZ-SPA

AC input voltage 90-264VAC;
Short Circuit, over current, over voltage protection
Energy Efficiency level VI
Meets 6KV surge immunity level

PDF file download

Product Features

Input voltage	90-264VAC	Working temp.	-5 ~ 40℃
Input Current	1000mA	Storage temperature	-40 ~ 70℃
Average efficiency	Level 6 energy efficiency	(I.e.	5~95% RH, non-condensing
Standby power consumption	0.075W MAX	mean time between failures	At an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight	About 130g	Mechanical specifications	85(L) 51.0(W) 28(H)mm
Application places	Suitable for medical, information and information equipment power adapters	Safety standards	CB( IEC60601-1)、cULus(UL62368)、RCM(AS/NZS62368-1)、PSE(J62368-1)、PSB(IEC62368-1)、CB( IEC62368-1)、FCC(Part 15)

model

Voltage
(V)

Current
(A)

Rated wattage

(W)

Ripple
(mV)

115 230

Average efficiency(%)Min

UES36WZ-120YYYSPA

12.0

0.01-3.00

36.0

200

Y Y

88.30

Input voltage	90-264VAC	Working temp.	-5 ~ 40℃
Input Current	1000mA	Storage temperature	-40 ~ 70℃
Average efficiency	Level 6 energy efficiency	(I.e.	5~95% RH, non-condensing
Standby power consumption	0.075W MAX	mean time between failures	At an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight	About 130g	Mechanical specifications	85(L) 51.0(W) 28(H)mm
Application places	Suitable for medical, information and information equipment power adapters	Safety standards	CB( IEC60601-1)、cULus(UL62368)、RCM(AS/NZS62368-1)、PSE(J62368-1)、PSB(IEC62368-1)、CB( IEC62368-1)、FCC(Part 15)

model

Voltage
(V)

Current
(A)

Rated wattage

(W)

Ripple
(mV)

115 230

Average efficiency(%)Min

UES36WZ-120YYYSPA

12.0

0.01-3.00

36.0

200

Y Y

88.30

Product information
