UES180DZ-SPA - UE Electronic

UES180DZ-SPA

Comply with communication and medical safety certification
2 MOPP isolation protection
PF>0.95@230VAC full load
Leakage current ≤ 100μA
Working altitude 5000 meters

PDF file download Get a quote

Product Features

Input voltage	90-264VAC(Class I);80-264VAC(Class II)	Working temp.	-10 ~ 40℃
Input Current	3.0A, under 80/90VAC input conditions	Storage temperature	-20 ~ 60℃
Output voltage range	11-56V	(I.e.	10~90% RH, non-condensing
mean time between failures	At an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight	800g	Mechanical specifications	165(L) 69.5(W) 24.25(H)mm
Application places	Suitable for medical and information equipment power adapters	Safety standards	CB( IEC60601-1/ IEC60601-1-11/ IEC62368-1) UL(ANSI/AAMI ES60601-1/60601-1-11/CAN/CSA C22.2 NO.60601-1 /UL62368-1) TUV SUD/Mark(EN60601-1 /EN60601-1-11) TUV-SUD-GS(EN62368-1) CE(EN62368) CCC(GB4943.1) FCC(FCC PART 15)

model	Voltage	Current	Watts	Ripple and noise	Voltage tolerance	Linear and load regulation	Average efficiency	Start delay time
UES180DZ-XXXYYYSPAZ	11.0-12.0	0.01-12.50	150W	150mVpk-pk	± 5%	Linear adjustment rate: ± 1% Load: ± 5%	92.00 %	≤3s
	12.1-13.0	0.01-11.53	150W	150mVpk-pk	± 5%		92.00 %	≤3s
	13.1-14.0	0.01-10.71	150W	150mVpk-pk	± 5%		92.00 %	≤3s
	14.1-15.0	0.01-10.00	150W	150mVpk-pk	± 5%		92.00 %	≤3s
	18.1-19.0	0.01-9.47	180W	190mVpk-pk	± 5%		93.00 %	≤3s
	19.1-20.0	0.01-9.00	180W	200mVpk-pk	± 5%		93.00 %	≤3s
	20.1-21.0	0.01-8.57	180W	210mVpk-pk	± 5%		93.00 %	≤3s
	21.1-22.0	0.01-8.18	180W	220mVpk-pk	± 5%		93.00 %	≤3s
	22.1-23.0	0.01-7.82	180W	230mVpk-pk	± 5%		93.00 %	≤3s
	23.1-24.0	0.01-7.50	180W	240mVpk-pk	± 5%		93.00 %	≤3s
	24.1-25.0	0.01-7.20	180W	250mVpk-pk	± 5%		93.00 %	≤3s
	25.1-26.0	0.01-6.92	180W	260mVpk-pk	± 5%		93.00 %	≤3s
	35.1-36.0	0.01-5.00	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	36.1-37.0	0.01-4.86	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	37.1-38.0	0.01-4.73	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	38.1-39.0	0.01-4.61	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	39.1-40.0	0.01-4.50	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	47.1-48.0	0.01-3.75	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	48.1-49.0	0.01-3.67	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	49.1-50.0	0.01-3.60	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	50.1-51.0	0.01-3.52	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	51.1-52.0	0.01-3.46	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	52.1-53.0	0.01-3.39	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	53.1-54.0	0.01-3.33	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	54.1-55.0	0.01-3.27	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	55.1-56.0	0.01-3.21	180W	400mVpk-pk	± 5%		94.00 %	≤3s

Input voltage	90-264VAC(Class I);80-264VAC(Class II)	Working temp.	-10 ~ 40℃
Input Current	3.0A, under 80/90VAC input conditions	Storage temperature	-20 ~ 60℃
Output voltage range	11-56V	(I.e.	10~90% RH, non-condensing
mean time between failures	At an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight	800g	Mechanical specifications	165(L) 69.5(W) 24.25(H)mm
Application places	Suitable for medical and information equipment power adapters	Safety standards	CB( IEC60601-1/ IEC60601-1-11/ IEC62368-1) UL(ANSI/AAMI ES60601-1/60601-1-11/CAN/CSA C22.2 NO.60601-1 /UL62368-1) TUV SUD/Mark(EN60601-1 /EN60601-1-11) TUV-SUD-GS(EN62368-1) CE(EN62368) CCC(GB4943.1) FCC(FCC PART 15)

model	Voltage	Current	Watts	Ripple and noise	Voltage tolerance	Linear and load regulation	Average efficiency	Start delay time
UES180DZ-XXXYYYSPAZ	11.0-12.0	0.01-12.50	150W	150mVpk-pk	± 5%	Linear adjustment rate: ± 1% Load: ± 5%	92.00 %	≤3s
	12.1-13.0	0.01-11.53	150W	150mVpk-pk	± 5%		92.00 %	≤3s
	13.1-14.0	0.01-10.71	150W	150mVpk-pk	± 5%		92.00 %	≤3s
	14.1-15.0	0.01-10.00	150W	150mVpk-pk	± 5%		92.00 %	≤3s
	18.1-19.0	0.01-9.47	180W	190mVpk-pk	± 5%		93.00 %	≤3s
	19.1-20.0	0.01-9.00	180W	200mVpk-pk	± 5%		93.00 %	≤3s
	20.1-21.0	0.01-8.57	180W	210mVpk-pk	± 5%		93.00 %	≤3s
	21.1-22.0	0.01-8.18	180W	220mVpk-pk	± 5%		93.00 %	≤3s
	22.1-23.0	0.01-7.82	180W	230mVpk-pk	± 5%		93.00 %	≤3s
	23.1-24.0	0.01-7.50	180W	240mVpk-pk	± 5%		93.00 %	≤3s
	24.1-25.0	0.01-7.20	180W	250mVpk-pk	± 5%		93.00 %	≤3s
	25.1-26.0	0.01-6.92	180W	260mVpk-pk	± 5%		93.00 %	≤3s
	35.1-36.0	0.01-5.00	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	36.1-37.0	0.01-4.86	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	37.1-38.0	0.01-4.73	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	38.1-39.0	0.01-4.61	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	39.1-40.0	0.01-4.50	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	47.1-48.0	0.01-3.75	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	48.1-49.0	0.01-3.67	180W	300mVpk-pk	± 5%		94.00 %	≤3s
	49.1-50.0	0.01-3.60	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	50.1-51.0	0.01-3.52	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	51.1-52.0	0.01-3.46	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	52.1-53.0	0.01-3.39	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	53.1-54.0	0.01-3.33	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	54.1-55.0	0.01-3.27	180W	400mVpk-pk	± 5%		94.00 %	≤3s
	55.1-56.0	0.01-3.21	180W	400mVpk-pk	± 5%		94.00 %	≤3s
