UES120DZ-SPA

  • Comply with communication and medical safety certification
  • 2 MOPP isolation protection
  • DOE Efficiency Level VI
  • CoC V5 Tier2(2016)
  • PF>0.95@230VAC full load
  • Leakage current ≤ 100μA
  • Standby power consumption≤0.15W
  • Working altitude 5000 meters
PDF file download
Product Features
Input voltage90-264VACWorking temp.-10 ~ 40℃
Input Current2.0A, under 80/90VAC input conditionsStorage temperature-20 ~ 60℃
Standby power consumption0.15W MAX(I.e.10~90% RH, non-condensing
mean time between failuresAt an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight450gMechanical specifications145.1(L)  69.5(W)  24.25(H)mm
Application placesSuitable for medical and information equipment power adaptersSafety standards
  • CB( IEC60601-1/IEC60601-1-11/ IEC62368-1)
  • UL(ANSI/AAMI ES60601-1/CAN/CSA C22.2 NO.60601-1 /UL62368-1)
  • TUV SUD/Mark(EN60601-1 /EN60601-1-11)
  • TUV-SUD/GS(EN62368-1)
  • CE(EN62368)
  • CCC(GB4943.1)
  • WHY(J62368)
  • KC(K60950-1)
  • FCC(FCC PART 15)
  • RCM(AS/NZS62368.1)

modelVoltageCurrentWatts

Ripple and noise

Voltage tolerance

Linear and load regulationAverage efficiencyStart delay time
UES120D”Z”XXXYYYSPA     11.0-12.0 0.01-10.0120W150mVpk-pk± 5%Linear adjustment rate: ± 1%
Load: ± 5%		92.00%≤3s
12.1-13.0 0.01-9.23120W150mVpk-pk± 5%92.00%≤3s
13.1-14.0 0.01-8.57120W150mVpk-pk± 5%92.00%≤3s
14.1-15.0 0.01-8.00120W150mVpk-pk± 5%92.00%≤3s
17.1-18.0 0.01-6.66120W180mVpk-pk± 5%93.00%≤3s
18.1-19.0 0.01-6.31120W180mVpk-pk± 5%93.00%≤3s
19.1-20.0 0.01-6.00120W200mVpk-pk± 5%93.00%≤3s
20.1-21.0 0.01-5.71120W200mVpk-pk± 5%93.00%≤3s
21.1-22.0 0.01-5.45120W200mVpk-pk± 5%93.00%≤3s
22.1-23.0 0.01-5.21120W200mVpk-pk± 5%93.00%≤3s
23.1-24.0 0.01-5.00120W240mVpk-pk± 5%93.00%≤3s
24.1-25.0 0.01-4.80120W240mVpk-pk± 5%93.00%≤3s
25.1-26.0 0.01-4.61120W240mVpk-pk± 5%93.00%≤3s
26.1-27.0 0.01-4.44120W240mVpk-pk± 5%93.00%≤3s
33.1-34.00.01-3.52 120W300mVpk-pk± 5%94.00%≤3s
34.1-35.00.01-3.42120W300mVpk-pk± 5%94.00%≤3s
35.1-36.0 0.01-3.33120W300mVpk-pk± 5%94.00%≤3s
36.1-37.0 0.01-3.24120W300mVpk-pk± 5%94.00%≤3s
37.1-38.0 0.01-3.15120W300mVpk-pk± 5%94.00%≤3s
38.1-39.0 0.01-3.07120W300mVpk-pk± 5%94.00%≤3s
39.1-40.0 0.01-3.00120W300mVpk-pk± 5%94.00%≤3s
47.1-48.0 0.01-2.50120W400mVpk-pk± 5%94.00%≤3s
48.1-49.0 0.01-2.44120W400mVpk-pk± 5%94.00%≤3s
49.1-50.0 0.01-2.40120W400mVpk-pk± 5%94.00%≤3s
50.1-51.0 0.01-2.35120W400mVpk-pk± 5%94.00%≤3s
51.1-52.0 0.01-2.30120W400mVpk-pk± 5%94.00%≤3s
52.1-53.0 0.01-2.26120W400mVpk-pk± 5%94.00%≤3s
53.1-54.0 0.01-2.22120W400mVpk-pk± 5%94.00%≤3s
Input voltage90-264VACWorking temp.-10 ~ 40℃
Input Current2.0A, under 80/90VAC input conditionsStorage temperature-20 ~ 60℃
Standby power consumption0.15W MAX(I.e.10~90% RH, non-condensing
mean time between failuresAt an ambient temperature of 25°C, the mean time between failures at maximum load is 100,000 hours (according to MIL-HDBK-217 standard)
weight450gMechanical specifications145.1(L)  69.5(W)  24.25(H)mm
Application placesSuitable for medical and information equipment power adaptersSafety standards
  • CB( IEC60601-1/IEC60601-1-11/ IEC62368-1)
  • UL(ANSI/AAMI ES60601-1/CAN/CSA C22.2 NO.60601-1 /UL62368-1)
  • TUV SUD/Mark(EN60601-1 /EN60601-1-11)
  • TUV-SUD/GS(EN62368-1)
  • CE(EN62368)
  • CCC(GB4943.1)
  • WHY(J62368)
  • KC(K60950-1)
  • FCC(FCC PART 15)
  • RCM(AS/NZS62368.1)

modelVoltageCurrentWatts

Ripple and noise

Voltage tolerance

Linear and load regulationAverage efficiencyStart delay time
UES120D”Z”XXXYYYSPA     11.0-12.0 0.01-10.0120W150mVpk-pk± 5%Linear adjustment rate: ± 1%
Load: ± 5%		92.00%≤3s
12.1-13.0 0.01-9.23120W150mVpk-pk± 5%92.00%≤3s
13.1-14.0 0.01-8.57120W150mVpk-pk± 5%92.00%≤3s
14.1-15.0 0.01-8.00120W150mVpk-pk± 5%92.00%≤3s
17.1-18.0 0.01-6.66120W180mVpk-pk± 5%93.00%≤3s
18.1-19.0 0.01-6.31120W180mVpk-pk± 5%93.00%≤3s
19.1-20.0 0.01-6.00120W200mVpk-pk± 5%93.00%≤3s
20.1-21.0 0.01-5.71120W200mVpk-pk± 5%93.00%≤3s
21.1-22.0 0.01-5.45120W200mVpk-pk± 5%93.00%≤3s
22.1-23.0 0.01-5.21120W200mVpk-pk± 5%93.00%≤3s
23.1-24.0 0.01-5.00120W240mVpk-pk± 5%93.00%≤3s
24.1-25.0 0.01-4.80120W240mVpk-pk± 5%93.00%≤3s
25.1-26.0 0.01-4.61120W240mVpk-pk± 5%93.00%≤3s
26.1-27.0 0.01-4.44120W240mVpk-pk± 5%93.00%≤3s
33.1-34.00.01-3.52 120W300mVpk-pk± 5%94.00%≤3s
34.1-35.00.01-3.42120W300mVpk-pk± 5%94.00%≤3s
35.1-36.0 0.01-3.33120W300mVpk-pk± 5%94.00%≤3s
36.1-37.0 0.01-3.24120W300mVpk-pk± 5%94.00%≤3s
37.1-38.0 0.01-3.15120W300mVpk-pk± 5%94.00%≤3s
38.1-39.0 0.01-3.07120W300mVpk-pk± 5%94.00%≤3s
39.1-40.0 0.01-3.00120W300mVpk-pk± 5%94.00%≤3s
47.1-48.0 0.01-2.50120W400mVpk-pk± 5%94.00%≤3s
48.1-49.0 0.01-2.44120W400mVpk-pk± 5%94.00%≤3s
49.1-50.0 0.01-2.40120W400mVpk-pk± 5%94.00%≤3s
50.1-51.0 0.01-2.35120W400mVpk-pk± 5%94.00%≤3s
51.1-52.0 0.01-2.30120W400mVpk-pk± 5%94.00%≤3s
52.1-53.0 0.01-2.26120W400mVpk-pk± 5%94.00%≤3s
53.1-54.0 0.01-2.22120W400mVpk-pk± 5%94.00%≤3s
