UES06WZ-SPA
- Compliant with communications and medical safety certifications
- 2 MOPP isolation protection
- Comply with medical deviceBF(∧)level
- Leakage current ≤ 10
- DOE efficiency level VI
- CoC V5 Tier 2(2016)
- Working altitude 5000 meters
- 4.2VTo12VOutput, highest6W
- Equipped with various interchangeable stylesACpin
Product Features
| Input voltage | 90-264VAC | Operating temperature | 0〜45 ℃ | ||||||||
| Input Current | 0.2A | Storage temperature | -20~60℃ | ||||||||
| Output voltage range | ± 5% | Working humidity | 10~90%RH, no condensation | ||||||||
| Storage humidity | 5~90% RH | mean time between failures | > 100,000 hours MIL-HDBK-217 at 25°C ambient temperature. | ||||||||
| weight | About 85g | Mechanical specifications | 73.5 (L) 42.5(W) 30.7(Hmm | ||||||||
| Application places | Suitable for medical and ITE equipment power adapters | Safety standards | CCC( GB4943.1)、CB(IEC60601-1/IEC60950-1/IEC62368-1)、TUV-Mark(EN60601-1 )、TUV Rheinland-GS(EN60950-1 /EN623368-1) 、RCM(AS/NZS 60950.1)、PSE(J60950-1)、KC(K60950-1(4.2 to 6VDC model only))、FCC(FCC PART15)、BIS(IEC60950-1:2005)、NOM(NOM-001-SCFI-1993)、UL(ANSI/AAMI ES60601-1/CAN/CSA C22.2 NO.60601-1/UL60950-1/UL62368-1/CAN/CSA C22.2 NO.60950-1) | ||||||||
model | Voltage | Current | Ripple | Voltage tolerance | Linear and Negative Adjustment Rates | Average efficiency | Start delay time |
UES06WZ-XXXYYYSPA | 4.2 | 0.01-1.20 | 200 | ± 5% |
| 73.83% | ≤3s |
5.0-6.0 | 0.01-1.00 | 150 | ± 5% |
| 73.77% | ≤3s | |
6.1-7.0 | 0.01-0.86 | 150 | ± 5% |
| 78.16% | ≤3s | |
7.1-8.0 | 0.01-0.75 | 200 | ± 5% | Linear adjustment rate:±1% | 78.26% | ≤3s | |
8.1-8.9 | 0.01-0.67 | 200 | ± 5% | Hello Elena:±5% | 78.38% | ≤3s | |
9.0-10.0 | 0.01-0.60 | 200 | ± 5% |
| 78.35% | ≤3s | |
10.1-11.0 | 0.01-0.54 | 200 | ± 5% |
| 78.42% | ≤3s | |
11.1-12.0 | 0.01-0.50 | 200 | ± 5% |
| 78.53% | ≤3s |
